SCP160E

SANY_Slider_SY16C_1920x775px
SCP160E
HIGH LEVEL
ON HIGH
VOLTAGE
PERFORMANCE, SUSTAINABILITY, INNOVATION

Class
Heavy-duty-forklift

Engine
LVKON

Rated power
100 kW

Lifting capacity
16 000 kg

Operating mass
23 000 kg

TOP HIGHLIGHTS

+ High efficient drive modes

+ Less maintenance requirements

+ Fast charging with dual gun

+ Reduced noise level

DEALER LOCATOR

With our European SANY Dealers, you will always find a location next to you.

Dealer locator

DOWNLOAD

Flyer Full Electric Heavy-Duty Forklifts
Download  [PDF 1.7 MB]
  • SCP160E_web_01
  • SCP160E_web_02
  • SCP160E_web_03
  • SCP160E_web_04
  • SCP160E_web_05
  • SCP160E_web_06

TECHNICAL SPECIFICATIONS

ENGINE
Drive motor power100kW
Pump motor power75kW
Battery rated voltage618V
Battery rated capacity210kWh
DRIVING AND LIFTING PERFORMANCE
Lifting capacity16 000kg
Lifting speed without/with load400 / 450mm/s
Lowering speed without/with load450 / 430mm/s
Lifting height, standard4 000mm
DIMENSIONS
Overall weight23 000kg
Total length8 094mm
Transport width2 834mm
Transport height3 754mm
Outer turning radius5 200mm
