Class
Telehandlers
Engine
Dana 301
Rated power
32 kW
Maximum lifting height
6 m
Load capacity
2,500 kg
OUR HIGHLIGHTS
+ No service or diesel filters to replace
+ Easy and quick battery charging
+ Low noise and vibration levels
DEALER LOCATOR
With our European SANY Dealers, you will always find a location next to you.
DOWNLOAD
TECHNICAL SPECIFICATIONS
QUALITY REALLY DOES CHANGE THE WORLD
SANY’s telehandler range is designed to meet the exact needs of the construction and rental industry. Coming will be a wide range of different styles and sizes, SANY’s versatile telehandler offers you all the safety, durability, versatility and low cost of ownership that you need to compete in today’s construction market.
| ENGINE | ||
| Rated power | 32 | kW |
| PERFORMANCE PARAMETERS | ||
| Maximum lift capacity | 2 500 | kg |
| Lift capacity at maximum height | 2 000 | kg |
| Lift capacity at maximum reach | 800 | kg |
| Lift height | 6 000 | mm |
| DIMENSIONS | ||
| Length to front of carriage | 4 000 | mm |
| Overall width | 1 850 | mm |
| Height over cab without beacon | 1 920 | mm |
| Height over cab with beacon | 2 010 | mm |
| Wheelbase | 2 390 | mm |
STANDARD EQUIPMENT
MORE FEATURES, MORE POSSIBILITIES
All SANY telehandlers are comprehensively equipped ex works, meaning that they quickly prove themselves as powerful all-rounders. With numerous options and attachments, they can be individually configured as necessary – leaving them perfectly equipped for the respective requirements.
› 10-inch touchscreen display and encoder navigation
› Heater and air conditioning
› Radio with Bluetooth and microphone
› Adjustable seat with suspension
› 12 V power socket
› Sunblind, roof and front screen
› Heated rear screen
› Front, roof and rear wiper and washers
› Armrest with storage and USB charger
› Cup and bottle holders
› Fully adjustable steering column
› Intuitive keypad functions (all backlit)
› EVI Telematics
› CE / UKCA-certified
› ROPS ISO:3471:2008 and FOPS ISO:3449:2005
› Screen and roof guard (optional)
› Reversing alarm
› Hi-viz seatbelt
› Integrated reversing camera and distance sensor
› Seat switch and green „ready“ beacon
› Load weight monitoring
› Load moment Indicator display
› Standard Sany Fast Fit carriage with 1 200 mm forks
› Manitou carriage with fork frame (optional)
› On board charger
› External 3 phase fast charge: optional
› Three steering modes: 4WS, 2WS and crab
› Fully proportional joystick
› Auxiliary hydraulic venting from cab
› 7 x LED Working lights on cab and boom
› Full LED road lights
› Amber flashing beacon
